The Agilent TwisTorr 84 FS-AG rack controller

State: In stock

The TwisTorr 84 FS-AG rack controller is a microprocessor controlled frequency converter with, enhanced features that allow greater control and communication capabilities. This compact, ¼ rack unit is designed for full worldwide compatibility, vent valve control, active gauge pressure reading, and pump operation parameters control. As well as including self-diagnostic and protection features.

Warranty: No warranty infomation

Price: Contact us

Order

Delivery time: 8h00 - 18h00 daily
Genuine product, provided width CO, CQ
03 months of free warranty for consumable and accessories
12 months of free warranty for main equipment
Accessorie's price is applied only when purchased with
main equipment
Contact us for any particular accessory's quotion

Email: info@redstarvietnam.com Every day in week

Features
Specifications
Downloads
Comments

Features

Universal voltage – the controller is able to auto set according to the input voltage, providing flexibility for easy installation worldwide
RS-232/485 communication protocols and Profibus (options)
Allows the pump to interact the system controls
Enables the pump to be operated via PC with T-plus software
Helps development of own customer software
Stop Speed Reading (SSR)
Continues pump speed reading after the stop command
Allows observation of the pump in slow down ramp and shut down time
N.O. and N.C. Vent Valve Drive
Valve delay and opening time adjustable
Vent valve driven by controller automatically or by serial line
Opening time control through SSR function

Order Information

Part Number	Description	Unit
9699883	A-PLUS Pump Control Software Kit, on Compact Disc, with 3 meter Serial Cable.
X3510-64000	Pump controller PCB, TwisTorr 84 FS turbo pump
X3508-64001	Pump controller, TwisTorr 84FS turbo pump, rack, RS232/486	1.7 (3.2)
X3508-64002	Pump controller, TwisTorr 84FS turbo pump, rack, Profibus	1.7 (3.2)
