The BBA231 is a robust and easy-to-operate bench scale for basic applications in dry and dusty industrial environments. The fast, user-friendly terminal can measurably improve production efficiency. It offers readability of up to 0.4g at a weighing capacity of 6 to 300kg..
Industrial Basic scales are quality scales at attractive prices. They are suitable for basic food, chemical or manufacturing applications in dry and wet environments. Take a look at the quality test in our test lab.
The IP65-rated scale is easy to operate. Five simple and intuitive to operate keys (On/Off, Zero, Tare, Clear, Print) plus two free definable function keys for easy set up and speedy handling. The straightforward setup of different functions requires minimal operator training.
Excellent readability under any light condition thanks to a large LCD display with adjustable white backlight.
Over/under checkweighing is performed easily and accurately with immediate status indication. Target-weight setup is simple, providing improved overall process accuracy.
The scale includes an RS232 interface, allowing for communication to a printer or PC.
The powder-coated steel load frame and a stainless-steel load plate make it highly durable while providing accurate weighing results.
Your collected data is centrally stored for easy analysis, in realtime, with tools such as Microsoft Excel. You can also take your visualizations on-the-go with web-based dashboards that can be accessed from any PC or mobile device.
| Maximum Capacity | 35 kg / 50 lb |
| Typical resolution | 15’000 d |
| Approvable resolution | OIML Class III, 3000e / NTEP Class III, 5000d |
| Approvable readability | 10 g / 0.01 lb |
| Platform size | 300 x 400 mm / 11.8" x 15.7" |
| Material | Terminal Housing: Plastic Platform Frame: Powder coated carbon steel Load Plate: Brushed stainless steel (1.4301 / AISI304) |
| Load Cell | Aluminum, Potted |
| Keypad | 7 membrane keys (On/Off, Zero, Tare, Function, Clear, Print, Function 1 & 2) |
| Display | 7-digit, 7-segment 60mm/2.36", LCD display with white backlight |
| Power supply | 85….264 VAC, 50/60 Hz |
| Ingress Protection | Terminal: IP54 Platform: IP65 |
| Applications | Straight weighing, counting, over/under checkweighing, totalizing, animal weighing |
| Interface | RS232 |
| Features | Date & Time (RTC), x10, Print, Unit switch, Target storage |
| Accessories | Stands, Roller Tracks, Ball Tops, Carts |
